Alüminyum Gövdeli Yüksek Basınç Piston Pompa
Alüminyum Gövdeli Yüksek Basınç Piston Pompa
| Product Code | Product Description | Displacement | Working Pressure |
Max. Intermittent Pressure |
Max.Peak Pressure |
Max.Continuous Speed |
Max.Speed at Intermittent Pressure |
Oil Temperature Range |
Oil inlet Diameter (C) |
Oil Outlet Diameter (D) |
Weight |
| 666038333 | PDV Straight Piston Pump (High Pressure) 38 Lt. | 38 cm³/rev | 350 bar | 400 bar | 430 bar | 1500 1/min | 1800 1/min | -20 & 80 °C | M45x2 | R 1" | 10 kg |
| 666046333 | PDV Straight Piston Pump (High Pressure) 46 Lt. | 46 cm³/rev | 10 kg | ||||||||
| 666054333 | PDV Straight Piston Pump (High Pressure) 54 Lt. | 54 cm³/rev | 11 kg |
